Ratchet Wrenches
LIST
3/8" sq. drive
KPT-1170
Bolt Capa.
10mm
Sq. Drive
9.5mm
Working Torque (Normal)
13-91Nm
Working Torque (Max)
160Nm
Free Speed
160rpm
Air Consumption
525l/m
Dimension
254×40×50(mm)
Net Weight
0.5kg
Air Inlet
1/4"
1/2" sq. drive
KPT-1175
Bolt Capa.
10mm
Sq. Drive
12.7mm
Working Torque (Normal)
13-115Nm
Working Torque (Max)
160Nm
Free Speed
160rpm
Air Consumption
525l/m
Dimension
254×40×50(mm)
Net Weight
0.5kg
Air Inlet
1/4"
3/8" sq. drive
KPT-700
Bolt Capa.
10mm
Sq. Drive
9.5mm
Working Torque (Normal)
6-43Nm
Working Torque (Max)
55Nm
Free Speed
310rpm
Air Consumption
485l/m
Dimension
170x32x37(mm)
Net Weight
0.5kg
Air Inlet
1/4"
1/4" sq.drive
KPT-705
Bolt Capa.
10mm
Sq. Drive
6.35mm
Working Torque (Normal)
6-33Nm
Working Torque (Max)
55Nm
Free Speed
310rpm
Air Consumption
485l/m
Dimension
170x32x37(mm)
Net Weight
0.5kg
Air Inlet
1/4"
1/4" sq.drive
KPT-620
Bolt Capa.
8mm
Sq. Drive
6.35mm
Working Torque (Normal)
10-34Nm
Working Torque (Max)
68Nm
Free Speed
500rpm
Air Consumption
396l/m
Dimension
155x39x39(mm)
Net Weight
0.6kg
Air Inlet
1/4"
3/8" sq. drive
KPT-625
Bolt Capa.
10mm
Sq. Drive
9.5mm
Working Torque (Normal)
10-41Nm
Working Torque (Max)
68Nm
Free Speed
500rpm
Air Consumption
396l/m
Dimension
155x39x39(mm)
Net Weight
0.6kg
Air Inlet
1/4"
3/8" sq. drive
KPT-3171
Bolt Capa.
10mm
Sq. Drive
9.5mm
Working Torque (Normal)
13-120Nm
Working Torque (Max)
160Nm
Free Speed
180rpm
Air Consumption
648l/m
Dimension
270x47x47(mm)
Net Weight
1.3kg
Air Inlet
1/4"
1/2" sq. drive
KPT-3176
Bolt Capa.
10mm
Sq. Drive
12.7mm
Working Torque (Normal)
13-120Nm
Working Torque (Max)
160Nm
Free Speed
180rpm
Air Consumption
648l/m
Dimension
270x47x47(mm)
Net Weight
1.3kg
Air Inlet
1/4"
1/4" sq.drive
KPT-3300
Bolt Capa.
8mm
Sq. Drive
6.35mm
Working Torque (Normal)
6-33Nm
Working Torque (Max)
55Nm
Free Speed
220rpm
Air Consumption
566l/m
Dimension
200x36x42(mm)
Net Weight
0.6kg
Air Inlet
1/4"
3/8" sq. drive
KPT-3310
Bolt Capa.
10mm
Sq. Drive
9.5mm
Working Torque (Normal)
6-33Nm
Working Torque (Max)
55Nm
Free Speed
220rpm
Air Consumption
566l/m
Dimension
200x36x42(mm)
Net Weight
0.6kg
Air Inlet
1/4"
